Oil palm fibre dryer is especially designed to meet customers' need.
Up to now, we have designed different dryers used for drying the slag, limestone, coal powder, clay, sawdust, fiber, grass, oil palm fibre, chicken manure, ores, sand and others for our customers. With more than 20 years' experiences, our technology in drying industry is very mature. Our senior engineer is very professional in designing the dryer due to different materials their moisture in order to meet our customer's need. Our dryer have been exported to Bangladesh, India and many other countries. Most importantly, we are the manufacturer, which means we can provide best price for u.

This dryer mainly consists of cylinder, lifters, driving device, supporting device and sealing ring, cyclone dust collector, furnace. The design can be direct flow or counter flow. The heating source can be coal, electricity,gasoline, natural gas and so on. Our engineer can choose the right machine and technology for our customers according to the moisture content and capacity required.

Specifications	Capacity	Main motor		Main gear box		Weight
(m)	(t/h)	Power(kw)	Model	Model	Speed reduction rario	(t)
*Ø1.210**	2.5	7.5	Y160M-R3	ZL50-16-1	______	13.5
*Ø1.512**	3.3-4.9	10	Y160L-6-B3	JZQ500-111-2F	______	18.9
*Ø1.515**	4-6	18.5	Y200L1-6	JZQ500-111-2F	______	21
*Ø1.812**	4-6	18.5	Y160L-6	ZQ50-16II-2	16.46	22.83
*Ø2.212**	7-12	18.5	Y200L7-6	JZQ650III	31.5	37.6
*Ø2.214**	7-12	22	Y200L7-6	JZQ650III	31.5	40
*Ø2.216**	12	30	Y225M-6	JZQ750III	31.5	45
*Ø2.414**	12	30	Y250M-6	JZQ750-III	31.5	51
*Ø2.418**	10-13	37	Y250M-6	ZL85-13-1	27.16	54
*Ø2.420**	10-14	37	Y250N-6	ZL85-13-1	27.16	54.14
*Ø3.020**	25	55	Y250N-4	ZL100-16-1	41.52	78
*Ø3.025**	32-36	75	YR280M-4	ZL100-16-1	41.52	104.9
